Peltier PC Cooling: Smart Laptop Cooling System with Real-Time Monitoring

Problem Statement

Laptops used for gaming often face overheating issues due to static and inefficient cooling solutions. These traditional methods: Collect dust Reduce performance Lack user control Do not adapt dynamically to temperature changes There is a need for an affordable, efficient, and user-friendly cooling system that offers real-time temperature control and enhanced usability for laptop gamers.

Contributors

Dhruv Golcha Aadit Reuben

View Documentation

About Peltier PC Cooling: Smart Laptop Cooling System with Real-Time Monitoring

Solution

The final design is a smart Peltier-based cooling system with: Real-time temperature monitoring OLED display for instant feedback Wi-Fi connectivity for alerts Data logging feature Multiple power usage profiles Built-in adjustable laptop stand for better airflow and posture The system offers an all-in-one, portable, USB-powered thermal solution for laptop users, especially gamers.

Additional Info

Objectives: Cool the bottom panel hotspot of laptops Operate using USB-C power (via phone chargers or USB4 port) Record temperature using built-in sensors Offer user-selectable cooling presets Adjust power dynamically based on presets and temperature data Display live temperature and power usage via an OLED screen Include ergonomic features (adjustable tilt, laptop stand, mobile holder, cable management) Measuring Success: Success was measured using: Performance graphs comparing thermal assistance levels (0W, 20W, 40W…) Evaluation of portability, extra features, ease of use, and safety

Image Gallery
